Color: RGB Illusion

Built in power on reset and power off reset circuits

The R/G/B ports have a maximum withstand voltage of 13V and a driving current of 5mA

Built in data shaping circuit

256 level grayscale adjustable

The data transmission frequency can reach 800Kbps

When the refresh rate is 30 frames per second, the number of chip cascades can be no less than 1024 points

Application areas: full-color luminous characters, full-color modules, point light sources, full-color light strips, light strip screens, color screen displays
